ESD CVC Twill 1.0 Grid Antistatisches, leitfähiges, antistatisches Polyester-ESD-Gewebe

  • CJTI
  • China
  • 20 TAGE
  • 10.000.000 M/JAHR
  • FA001021

Es gibt viele Arten dieser Art von Stoff, wie zum Beispiel:
1. PES: 39 %; Baumwolle: 59 %; leitfähige Kohlefaser: 2 %;
2. Antistatisches TC-Gewebe 64 % Polyester 34 % Baumwolle 2 % leitfähiges Garn;
3. Antistatisches FR-Gewebe;
4. Antistatisches CVC-Gewebe.
Unterschiedliche Gewebetypen passen sich den Anforderungen unterschiedlicher Antistatik- oder Reinraumumgebungen an. Weit verbreitet in der Mikroelektronik, optischen Elektronik, Präzisionsinstrumenten und in der Luft- und Raumfahrt, die empfindlicher auf statische Elektrizität reagieren und höhere Anforderungen an den Freiraum stellen.

ein Angebot bekommen? Jetzt Anfrage senden

Specification of Antistatic CVC Fabric 1.0 Grid

Antistatic CVC fabric


NameESD Anti-static CVC twill fabric 1.0 grid for work wear
CodeWhite   (FA001021-01)
Blue grey   (FA001021-02)
Shallow pea green   (FA001021-03)
Silver grey   (FA001021-04)
MaterialPES : 39 % ; Cotton : 59 % ; conductive carbon fiber : 2 %
Specification2/1 left twill
Yarn count32s*32s
WeightG/M2
Width144cm
Color (customizable)Code
UsePetrochemicals,minerals,electronics and electrical appliances,food,national defense,commercial manufacture,automobile etc.


Features of ESD CVC Twill 1.0 Grid

polyester Esd Fabric

There are many types of this kind of antistatic ESD fabric such as:

1. PES : 39 % ; Cotton : 59 % ; conductive carbon fiber : 2 %;

2. Anti-static TC fabric 64% polyester + 34% cotton + 2% conductive yarn;

3. Antistatic FR fabric;

4. Antistatic CVC fabric.

Different type fabrics adapt to the requirements of different anti-static or cleanroom environment. Widely used in microelectronics, optical electronics, precision instruments, and aerospace which are more sensitive to static electricity and have higher requirements in clearnoom.


Description:

High Quality 10Mm Grid Or Strip Cotton and Polyester Esd Fabric For Cleanroom Garment.

Anti-static cloth is made of conductive fiber.

It's mainly used in the production of dust-proof clothing, anti-static clothing, anti-static mask, anti-static glove, anti-static shoe and shoe cover.

The fabric is 1.44m wide, surface resistance 10^6Ω-10^8Ω, available for class1000 cleanroom.


Antistatic ESD fabric

Antistatic CVC fabric

polyester Esd Fabric

Antistatic ESD fabric


The Application of Antistatic Fabric

CJTI ESD fabric can be tailored as kinds of ESD clothing and its accessories, is widely used in microelectronics, optoelectronics, precision instruments, aerospace and other fields that are extremely sensitive to electrostatic phenomena.


Antistatic CVC fabric


CJTI Certifications

After years of hard work, CJTI has obtained more than 50 technology patents and awards in functional fabrics.


polyester Esd Fabric


CJTI R&D and Production Center

Antistatic ESD fabric

CJTI in Global Market

Antistatic CVC fabric
